Application:TFM sanitary filter housing is designed for sanitary, pharmaceutical, biological, biotechnological, food and beverage applications, constructed in stainless steel 304 or 316L with a crevice free design. Designed for hot water, chemical a

Inquire Now PDF Datasheet

Application

TFM sanitary filter housing is designed for sanitary, pharmaceutical, biological, biotechnological, food and beverage applications, constructed in stainless steel 304 or 316L with a crevice free design. Designed for hot water, chemical and steam sterilisation. Ideal for use with filter cartridges ranging from clarification to sterilising grade membranes. Suitable for applications where CIP and SIP cleaning and sterilization procedures are required.

Materials

  • Cartridge housing material :SS304/SS316L
  • Clamp :SS304
  • Tri clamp Gasket:Silicon per FDA 177.2600
  • Venting (optional):SS304/SS316L
  • Draining (optional) :SS304/SS316L

Standard Design

  • T type Design
  • High-quality and crevice free construction
  • Tri-Clamp Closure
  • Sanitary process, vent & drain connections
  • Cartridges in 222/Fin or 226/Fin configurations
  • Single cartridge
  • Length of filter cartridges: 10", 20", 30", 40"

Technical Specification

  • Temperature range: -10°C to 120°C(Silicon)

  • Working Pressure: 8 bar up to 40 °C

  • Steam Sterilization :121°C/ 30 min
