QiiMii UHV (Ultra-high Vacuum) Multi-CF Vacuum Chambers are precise, modular, multi-port fittings and housings that utilize integrated ConflatTM (CF) sealing surfaces at each port.
English
English
Material:SS304
ISO flanges are larger than KF flanges, similar to the KF flanges, they use a centering ring for sealing ISO flanges are widely used in systems that need frequent cleaning or disassembly.
There are two different methods to join the flanges together:1. Bolts (ls0-f see diagram C) or 2. Claw clamps (ls0-k, see diagram A). These two flanges look very different, yet they can be joined together by using a single claw clamp (see diagram B).
 |
Model for 304 | Size(ISO/NW) | A/mm | B/mm | C/mm | N.W./g |
| FLG841S634 | 63 | 95 | 86.5 | 4 | ||
| FLG841S804 | 80 | 110 | 96.1 | 4 | ||
| FLG841S1004 | 100 | 130 | 116.2 | 4 | ||
| FLG841S1254 | 125 | 154.8 | 146.5 | 4 | ||
| FLG841S1604 | 160 | 179.8 | 169.5 | 4 | ||
| FLG841S2004 | 200 | 240 | 227 | 4 | ||
| FLG841S2504 | 250 | 289.5 | 276.6 | 4 | ||
| FLG841S3204 | 320 | 369.5 | 332.4 | 5.5 |
QiiMii UHV (Ultra-high Vacuum) Multi-CF Vacuum Chambers are precise, modular, multi-port fittings and housings that utilize integrated ConflatTM (CF) sealing surfaces at each port.
