ISO 90° Elbow

Name: ISO 90° Elbow
Brand: QIMING
SKU: 00343
Rating: 4.1 (222 reviews)

ISO-KF fittings can be used in a wide variety of applications including: • Roughing and foreline plumbing • Small systems • Systems requiring frequent cleaning or modification • Research a

Categories:	ISO Flange Series
FOB Port:	Ningbo, Zhejiang
Terms of Payment:	Western Union,T/T Paypal
Delivery Time:	15 Working Days

Inquire Now

Description

ISO Flange Assembly Instructions

Optional fastener flanges are joined around the periphery with clamps.
Double claw clamps are used when a pair of OF flanges are joined (See diagram A.),
or single claw clamps are used to join an OF flange to a tapped nonrotatable on a pump or gate valve. (See diagram B.)
This fastening method allows the OF flange to be rotateforease of component alignment. Additionally, a rotatable bolt ring can be used to fasten an OF flange to a nonrotatable flange using bolts. (See diagram C.)
A retainer ring prevents the OF flange from slipping through the bolt ring. Nonrotatable ISO flanges are assembled with bolts.
(See diagram D.) They do not allow rotation of bolt holes on mating flanges to align components.
