InquireISO-KF fittings can be used in a wide variety of applications including:
• Roughing and foreline plumbing
• Small systems
• Systems requiring frequent cleaning or modification
• Research and teaching laboratories
ISO-KF components are primarily designed for use at subatmospheric pressure. Because of the large number of elastomer seals used.
The ISO-KF system is a modular, building block method ofcreating a piping system. There are several advantages in the use of ISO components. Since component dimensions are standardized, elbows,tees, crosses or valves for a given size may be interchanged. The flanges are ''sexless'' and the seal is symmetrical, so that the components are rotatable. By using ISO components, system assembly is quick and cost effective. See Figure 1 for the ISO dimensions of flange sizes 10, 16, 25, 40 and 50. These dimensions apply to ISO-KF flanges of these nominal diameters throughout this catalog.
The ISO-KF components are assembled by inserting a centering ring between the two flange faces, then securing the assembly with a flange encompassing clamp (see Figure 2).
Elastomer seal: >= 1 x 10-8 Torr
Viton: -50°C to 200°C
Roughing and foreline plumbing; Small systems; Systems requiring frequent cleaning or modification; Resea...
InquireRoughing and foreline plumbing; Small systems; Systems requiring frequent cleaning or modification; Resea...
InquireISO-KF fittings can be used in a wide variety of applications including: • Roughing and foreline plumb...
InquireApplicationISO-KF fttings can be used in a wide variety of aplications including:●Roughing and foreline p...
InquireOn July 20th, our 8th anniversary group building event. Gratitude for eight years, building the future together, and creating brilliance again.
Size Flange OD Tube IDTube OD Inch mm 1/2"0.984250.370 9.40.500 12.70 3/4"0.984250.620 15.750.750 19.05 1"1.98450.50.870 22.11.000 25.40 11/2"1.98450.51.370 34.81.500 38.10 2"2.516641.870 47.5
