Elongated Ellipse Sight Glass fitting to DIN28120 Stainless Steel LEVEL INDICATOR

Application

To show surface of a liquid, for insertion into attachment totanks, vessels and silos.The base frame is welded onto or into the vessel wall. Then the sightglass plate together with two seals is firmly bolted down
by the cover frame and a set of fastening bolts

Materials

• Body Materials: AISI-304 or AISI-316L

• Tempered glass

• Gasket Material:Silicon, NBR, EPDM

comply with FDA 21CFR177.2600

DESIGN AND FEATURES

   · Wide range of sizes
   · High Pressure versions up to 25 Bar
   · Low profile, clean-line design with counter-sunk bolts
   · Radius base flange available for flush fit with vessel interior

Standard Design

• Available in size from 1"-4", DN25-DN100 or others upon requirement

• Standards: DIN, SMS, ISO / IDF, BS / RJT, ASME / BPE.

• End connections: Welding customized

Technical Specification

• Temperature range: 14 ~ 248℉ (-10 ~ 120℃), EPDM

• Surface treatment: CNC machining
