TSF03 Flange Type Sight Glass with Light Indicator

TSF Series flange type sight glass is widely used in food, wine-producing, beverage and pharmacy industries etc. For it is convenient to view the condition of equipment running state and system work state.

Categories: Sight Glass
FOB Port: Ningbo, Zhejiang
Terms of Payment: Western Union,T/T Paypal
Delivery Time: 15 Working Days
Inquire Now PDF Datasheet

Application

TSF Series flange type sight glass is widely used in food, wine-producing, beverage and pharmacy industries etc. For it is convenient to view the condition of equipment running state and system work state.

Materials

  • Body Materials: AISI-304 or AISI-316L

  • Tempered glass

  • Gasket Material:Silicon, EPDM, FRM

  • Seat and gasket  comply with FDA 21CFR177.2600

Standard Design

  • Available in size from 1"-4", DN25-DN100 or others upon requirement

  • Standards: DIN, SMS, ISO / IDF, BS / RJT, ASME / BPE.

  • End connections: butt-welded, sanitary clamp, or others upon request

  • Vertical or horizontal installation

  • 360 degree; view angle

Technical Specification

  • Temperature range: 14 ~ 248℉ (-10 ~ 120℃), Silicon

  • Surface treatment: CNC machining
